Hot Style Vacuum Belt Filter Press Filter Surface Flat Tensile Wear Resistance Filter Cloth

AnhulXurui Mesh lndustry Co., Ltd.ls the partneroftop 500enterprises,the deslgnatedsupplieroffive power plants,Xurui filtercloth stricttyselected Geman sas certified importedraw materials, service life >100000 hours,one yearaf quality assurance, Rushangloom largetension weaving, high longjtude and wetting,direction tightness, good stifiness, high tem pera-ture sha ping does not run off, SiN plasma treatmenitdoes not block mesh, Filtration efficiencyincreased by 6796,output increased by8096,annualincomeincreased by3 milion yuan. widetyused in power plant desulfurization, chemical industry, metallurgy, steelmaking, cement, ironore powderscreening, coalwashing, tallings drydischarge and other industries.

The filtration accuracy is improved by 10-25%
Save 10-20% of the cost
Direct transfer to the outside, without drying
Easy replacement, three minutes life

Customization

Complete product range, providing customization.
Customized logo(Min. order 1 set).

Contact Us

·Raw material imported from Germany·13 production QC processes line
·200% longer life·35000$ annual cost savings
·15-year experienced workers·28 years of R&D and production experience
·All kinds of interface·Imported alloy threading

Filter cloth material PET (polyester, modified with Teflon)
Filter cloth structure Weaving net, 1% per layer (one and a half layers)
Finally finalized Heat-setting
Filter cloth specification(mm) 2800X56100
Thickness 1.2mm-2.3mm
Breathability (at 200pa) 9m3/m2 min、90L/dm2min
Meridian Monofilament 0.50mm
Meridian density 280.0 pieces/10cm
Latitude  Single filament 0.50mm and fine yarn (short fiber yarn) 150tex
Latitude density 206.0 pieces/10cm
Filtration 25~65um
Longitudinal tensile strength 255kg/m
Lateral tensile strength 150kg/m
Axial line Monofilament 0.50mm
Axial linear density 280.0 pieces/10cm
Circular line Single filament 0.50mm and fine yarn (short fiber yarn) 150tex
Circular line density 206.0 pieces/10cm
